CNC machining centers for 3-axis machining | IBARMIA

3 axis models or in combination with horizontal rotary tables, IBARMIA can achieve the highest productivity by customizing working areas to specific production systems.

ZV spindle head
3 axis movement.
High Dynamics spindle.
Up to 12.000 rpm

Models

By construction size

Larger columns for even more
powerful spindles.

ZMV4

Medium size

Ibarmia, centros de mecanizado cnc, mecanizado 3 ejes, fresado 3 ejes, mecanizado vertical 3 ejes, mecanizado de piezas largas

Tool holder

SK-40 • BT-40 • HSK A-63 • CAPTO 6

Axis travels

X • Up to 12.000 mm | Y • 800 / 1000 mm |
Z • 700 / 800 mm | B • +/- 120º

Spindle

46 kW - 12.000 rpm

ZMV5

Medium size

Tool holder

SK-50 • BT-50 • HSK A-100 • CAPTO 8

Axis travels

X • Up to 12.000 mm | Y • 800 / 1000 mm |
Z • 700 / 800 mm | B • +/- 120º

Spindle

43 kW - 8.000 rpm

ZLV5

Large size

Tool holder

SK-50 • BT-50 • HSK A-100 • CAPTO 8

Axis travels

X • Up to 12.000 mm | Y • 800 / 1000 / 1100 mm |
Z • 950 mm (Op. 1150 mm) | B • +/- 120º

Spindle

84 kW - 12.000 rpm

Z Extreme

Main advantages

3 axis vertical machining

An endless range of solutions for efficient working areas, quick change over of parts etc... combined wit high speed spindles with the highest feed rates.

Trunnion fixtures

Custom made trunnion fixtures with specific clamping systems, possibility to work in pendulum etc.. excellent chip evacuation by removing the fixed table allowing a clear passage to the chip extraction system.
